Audio-Technica – AT-LP120XUSB – Direct Drive Turntable with USB – Black | |
The Audio-Technica AT-LP120XUSB is a mid-range direct-drive turntable introduced in 2009 by the Japanese audio equipment manufacturer Audio-Technica. The AT-LP120XUSB was intended to be a viable replacement for the long-running Technics SL-1200 series of turntables that was set to be discontinued in 2010. It supports both phono and line-level output using a built-in preamplifier.
The turntable also has the ability to dub records directly to a computer in real-time using a USB connection. At the January 2019 Consumer Electronics Show, an updated version called the AT-LP120XUSB was announced by Audio Technica. According to the company, the new model includes an improved internal preamp and comes with the company’s updated VM95E cartridge. |
|
Features | |
>Convert your vinyl records to digital audio files
>Mac- and PC-compatible Audacity software digitizes your records >Direct-drive, high-torque motor >Fully manual operation >Selectable 33/45/78 RPM speeds >Professional anti-resonance, die-cast aluminum platter with slip mat >½” mount universal headshell with AT95E Dual Magnet™ phono cartridge and long-life diamond stylus >Balanced S-shaped tone arm with hydraulically damped lift control and lockable rest >Built-in switchable phono pre-amplifier with RCA output cables >Stroboscopic platter with speed indicator >Forward/reverse operation and variable pitch control with quartz speed lock >Popup stylus target light for easier cueing in low light >Includes: Mac- and PC-compatible Audacity software, USB cable, Two output adapter cables (dual RCA female to mini-plug male & dual RCA female to mini-plug female), Power cord, 45 RPM adapter, Phono cartridge (78 RPM records require additional cartridge, not included), Counterweight, Slip mat, Removable hinged dust cover >Available in silver (AT-LP120-USB) and black (AT-LP120BK-USB) |
|
Turntable | |
Type | 3-speed, fully manual operation |
Motor | DC motor |
Drive Method | Direct drive |
Speeds | 33-1/3 RPM, 45 RPM, 78 RPM |
Turntable Platter | Die-cast aluminum |
Starting Torque | >1.6 kgf-cm |
Braking System | Electronic brake |
Wow and Flutter | <0.2% WRMS (33 RPM) |
Signal-to-Noise Ratio | >50 dB |
Output Level | Pre-amp “PHONO”: 2.5 mV nominal at 1 kHz, 5 cm/sec Pre-amp “LINE”: 150 mV nominal at 1 kHz, 5 cm/sec |
Phono Pre-Amp Gain | 36 dB nominal, RIAA equalized |
USB Function | A/D, D/A – 16 bit 44.1 kHz or 48 kHz USB selectable; Computer interface – USB 1.1 Compliant Windows XP, Vista or MAC OSX |
Power Supply Requirements | 115/230V AC, 60/50 Hz |
Dimensions | 450.0 mm (17.72″) W x 352.0 mm (13.86″) D x 157.0 mm (6.1″) H |
Weight | 10.7 kg (23.5 lbs.) |
Accessories Included | Headshell/cartridge; AC line cord; dual RCA (female) to 3.5 mm (1/8″) mini-plug (male) stereo adapter cable; dual RCA (female) to 3.5 mm (1/8″) mini-plug (female) stereo adapter cable; 45 RPM adapter; USB cable; recording software |
Pitch Variation | +/-10% or +/-20% |
Notes | Please note: As of September 2011, the AT-LP120XUSB includes the AT95E cartridge, replacing the ATP-2XN cartridge. |
